Iec Power Cable Types

View the range of lindy c13 c14 iec mains cables by clicking here.

Iec power cable types.

Euromain iec cold connector sometimes wrongly called a kettle lead c13 c14 2m on 0 75mm2 cores else 10m 70 c 10 0 kettle lead iec hot connector c15 c16 120 c 10 0 used extensively in recent hp servers and cisco kit c15a c16a 155 c 10 0 c17 c18 70 c 10 0 c19 c20 70 c 16 0. Other common power cord types also include c14 to c15 and c20 to c15. Established by the international electro technical commission iec these designations use the letter c followed by a number in their codes. Iec 60320 power cords uses even number for plug and odd number for the mating receptacle and usually male appliance inlet is 1 higher than the sheet for the corresponding female cable connector.

The iec chart serves as a guide for proper plug identification. Iec cords are used to power many pieces of electronic equipment including computers instrument amplifiers professional audio equipment and virtually all professional video equipment. Therefore the most common used power cord types is c14 to c13 and c20 to c19. These 13 types differ in essence in the intensity of current they are capable of withstanding but obviously they also have physical differences.

These connectors are the ones we usually find at the other end of power cables and refer to a set of no less than 13 types of connectors included in the iec 60320 specification. C1 c2 used for small electrical appliances such as electric trimmers or shavers. One of the most common plugs found on mainland europe is the schuko connector used in france germany and many other european countries. Iec power leads are most often used for connecting computers to a power source with a standard set of inlets and country specific cords.

Included in the iec chart are types of outlets inlet types pin spacing appliance class voltage amperage and more. C7 c8 the figure eight connector is commonly used in personal stereo systems and some older laptop models. Converts an iec c13 cold type power cable to an iec c15 hot type power cable. Us power cables have 2 rectangular prongs rated for a.

Schuko euro power cables. The c19 power cable is used in higher current applications such as power pdus in data centres it is an industrial type connector larger than the c13 and c15. Iec is the designation given to connectors used in some appliances and computers laptops. Iec c19 power cables.

Iec cables are the standard for connecting power supply to electrical devices up to 250 volts. This is a hot condition cable which means it is rated to withstand higher temperatures. A power cord with a suitable power plug for the locality where the appliance is being used on one end and a c13 connector connecting to the appliance on the other is commonly called an iec cord.
